Vertical Biomass pellet mill

Description:

This vertical biomass wood pellet machine is applied to make the agro-forestry wastes into solid fuels or wood pellets. Material:rice husk,sunflower seed husk,peanut shell and other fruit shell;branch,trunk,bark and other wood waste;a variety of corp straws,rubber,cement,ash and other chemical material. Industry:It is used in the biomass energy fuels plant,power plant,wood processing plant,fertilizer plant,chemical plant etc.

Share With:
  • Introduction
  • Technical Data
1. Application of Vertical Ring Die Wood Pellet Machine:
This vertical wood pellet machine is applied to the material with low adhesiveness and low shaping.
Material:rice husk,sunflower seed husk,peanut shell and other fruit shell;branch,trunk,bark and other wood waste;a variety of corp straws,rubber,cement,ash and other chemical material.
Industry:It is used in the biomass energy fuels plant,power plant,wood processing plant,fertilizer plant,chemical plant etc.It is the ideal pressing shaping equipments with low.

2. Main feature:
1.1.Vertical die,feeding vertically;No arching of raw materials,easy for heating dissipation
2.Die fixed,rollers rotating,materials centrifugal,evenly distributed around.
3.Double-layer dies,up and down dual-use,high capacity,saving energy.
4.Independent lubrication;high pressure filtration,clean and unblocked.
5.Independent and frequency changeable cutting device,ensure formation rate of pellets.


Model MZLV-470B MZLV-470G MZLV-480 MZLV-548
Capacity(t/h) 0.5-0.6 0.5-0.6 1.0 1~1.5
Main Power(kw) 55 55 75 90
Ring Die Dia(mm) 470 470 480 548
Type Belt Driving Gear Driving Gear Driving Gear Driving
Ring die Layer 1 2 2 2
Pellet size 6/8/10mm 6/8/10mm 6/8/10mm 6/8/10mm
